What is 5-Axis CNC Machining? [Definition, Decision Guide, and Practical Application]

1. What is 5-Axis CNC Machining?

5-axis CNC machining is an advanced manufacturing process that allows a cutting tool or part to move along five different axes—three linear (X, Y, Z) and two rotational (A, B, or C). This enables the machine to approach the workpiece from virtually any direction in a single setup.

  • Machining complex, freeform, or multi-face parts efficiently

  • Reducing manual repositioning and set-up errors

  • Improving accuracy and consistency

  • Shortening lead times for prototype and production parts

2. How Does 5-Axis Compare to 3-Axis CNC Machining?

Decision Table: When to Use 3-Axis or 5-Axis


Scenario / Requirement3-Axis CNC5-Axis CNC
Flat, prismatic parts✅✅
Multi-face or angled features❌ (multiple setups)✅ (single setup)
Deep or angled holes (>30° to surface)Limited✅
Tight tolerance across multiple facesChallengingEasier to control
Organic/Freeform surface (e.g. turbine)ImpossibleDesigned for this
High precision prototypePossiblePreferred for complexity
Batch production of simple parts✅ (cost effective)Overkill (higher cost)


Note: In real factories, if a part can be fully processed in one or two setups on a 3-axis machine, that’s the cost-effective choice. For parts with undercuts, angled holes, or multi-face accuracy needs, 5-axis is usually required.

3. Real-World Example: When Engineers Should Switch to 5-Axis

Case Example: Medical Device Housing
A customer submitted a drawing for a titanium implant housing with multiple angled holes and tight surface finish specs (Ra < 0.8 μm). Initial attempts with 3-axis CNC resulted in misalignment between the main bore and side features, requiring multiple setups and causing quality issues.

Switching to a 5-axis CNC machining process enabled:

  • All features machined in a single setup

  • Consistent tolerance control (±0.01mm achievable)

  • Surface finish met in one go

4. What Do Engineers Really Need to Ask When Sourcing CNC Machining?

Typical Questions and Answers

  1. Can my part be done on a 3-axis machine?
    If your part only has features on two opposite sides and no complex angles, likely yes.

  2. When is 5-axis mandatory?

    • Multi-face features requiring positional accuracy

    • Organic surfaces (e.g., impellers, orthopedic implants)

    • Deep/angled holes not parallel or perpendicular to reference surfaces

  3. Is 5-axis always more expensive?

    • Hourly machine cost is higher, but reduced setups often lower total cost and risk for complex parts

    • For simple, high-volume parts, 3-axis is still preferred for cost efficiency

  4. What’s the real precision difference?

    • 3-axis: ±0.02~0.05mm (typical, depends on setup skill and part geometry)

    • 5-axis: ±0.005~0.02mm for all faces in one setup (typical industrial tolerance range)

5. ISO 9001 Certification—Why Does It Matter?

ISO 9001 certified CNC manufacturers follow documented quality control processes:

  • Incoming material inspection

  • In-process and final dimensional checks

  • Full traceability and documentation

  • Customer complaint management and corrective actions

For customers, this means:

  • Consistent part quality across batches

  • Detailed inspection reports (can include FAI, PPAP on request)

  • Lower risk for regulated industries (medical, aerospace, automotive)

6. Practical Decision Flow

  1. Send your part drawing and specs

  2. Factory engineer reviews:

    • Complexity of geometry, number of faces, tolerance stack-up

    • Required surface finish and inspection

  3. Factory provides recommendation:

    • 3-axis is sufficient (faster, cheaper for simple geometry)

    • 5-axis required (if multi-face, complex, or precision needs)

  4. Optional: Request quote for both processes for comparison

7. Frequently Asked Questions

Q: My part has 4 sides with precision holes, but nothing too complex. Should I use 5-axis?
A: If each face can be accessed without removing/repositioning, 3-axis with rotating fixtures may be sufficient. If not, or if tolerances are tight between faces, 5-axis is safer.

Q: Does 5-axis always mean faster delivery?
A: For complex parts, yes—because there are fewer setups and less manual adjustment. For simple blocks, 3-axis is still quicker.

Q: What documentation does an ISO 9001 shop provide?
A: Usually: Certificate copy, batch traceability, inspection report, and upon request, FAI or PPAP documents.

8. Ready for Professional Advice?

Not sure which machining process is right for your part?


Upload your drawings/specs to BERGEK’s engineering team—get a free process review and tailored quote!


Want to learn more or share your technical questions?


Join our LinkedIn manufacturing group!
